iPeak® Plus
Reader for larger colorimetric tests
About iPeak® Plus
iPeak® Plus is IUL’s colorimetric lateral flow test reader for multi-strip assays, supporting qualitative, semi-quantitative and quantitative test.
Its open-platform design supports larger cassette formats, up to 5 strips per cassette and up to 7 lines per strip, making it suitable for more complex lateral flow test configurations.
Compact and easy to integrate, iPeak® Plus is designed for applications in human and veterinary diagnostics, food and beverage, pharmaceuticals, cosmetics, environmental testing and research. It can also be customized for OEM projects.
Built for long-term flexibility, iPeak® Plus allows new assays and cassette formats to be added over time while retaining the same reader platform.
Key Benefits
A market-ready lateral flow reader platform designed to support IVDR and U.S. regulatory requirements.
Advanced analytical performance delivers accurate, trustworthy results.
Accommodate larger devices of different formats, dimensions and configurations.
Enables data export, system connectivity, and full result traceability.
Workflow
Inoculate the test
Load the test to the reader
Select or load the cassette settings
Enter or scan the sample ID
Press SCAN or TIMED SCAN to read the test
Review and export the results
Product Insights
Optimized optics, advanced image processing, and cassette-specific drawers work together to deliver consistent, accurate, and repeatable measurements.
Custom 3D-printed drawers ensure a precise cassette fit and consistent test positioning at every scan.
An intuitive touchscreen, barcode verification, and role-based access make operation straightforward for every user.
Technical Specifications
| Order number | Cat. 900034000 |
| Lateral flow assay technology | Colorimetric |
| Number of strips | Up to 5* |
| Battery autonomy | Up to 4 hours |
| Measurement time | 13 ± 1 seconds |
| Number of lines per strip | Up to 7 lines* |
| Stored results in device | 200 (including images) |
| Supported assays | Qualitative, semi-quantitative, quantitative |
| Camera | High resolution CMOS |
| Connectivity | Wi-Fi, Ethernet, Printer, PC |
| Data export formats | PDF reports, CSV files, PNG images |
| User management | Administrator, Manager, Operator |
| LIMS / LIS integration | TCP/IP, SFTP, HL7 v2.8 |
| Certifications | CE-marked, UKCA-marked |
| Equipment dimensions (L×W×H) | 14 × 15.0 × 18.0 cm 5.5 × 5.8 × 7.1 in |
| Net weight | 0.9 kg / 1.9 lb |
*Discuss your cassette specifications with IUL.
Accessories
Tutorial Videos
Downloads
- Brochure iPeak® Family EN Download
Frequently Asked Questions
Yes. The iPeak® Plus is an open-system lateral flow reader designed to accommodate different colorimetric lateral flow cassette formats. A customized drawer can be developed to match the dimensions and geometry of your assay. IUL can evaluate your cassette design and configure the reader for your specific lateral flow test. (IUL)
The iPeak® Plus can analyze up to five lateral flow strips in one cassette, with up to seven lines per strip, depending on the cassette design and available reading area. This makes it particularly suitable for large or multiplex lateral flow cassettes. (IUL)
The iPeak® Plus can be configured for a specific lateral flow assay using IUL's assay-development software. During method development, parameters such as the reading region, test and control line positions, analysis settings, and result interpretation can be defined for the assay. The resulting method can then be transferred to the reader for routine testing. (IUL)
No. Once the assay method has been configured and transferred to the device, the iPeak® Plus operates as a standalone lateral flow reader for routine testing. A computer is primarily used during assay development and method configuration. (IUL)
Assay methods can be transferred to the iPeak® Plus using a Data Matrix code generated during method development. The reader scans the code to load the corresponding assay configuration, simplifying deployment of standardized methods across different devices or testing sites. (IUL)
Yes. The iPeak® Plus stores test results and images and supports data export through USB and network connectivity. Results can also be transferred to an external SFTP server or integrated with laboratory information systems using HL7-compatible connectivity, supporting traceability and centralized data management. (IUL)
The iPeak® Plus uses controlled illumination, image acquisition, and image-processing technology to provide objective analysis of colorimetric lateral flow tests. Its optical design helps reduce the influence of reflections, shadows, and subjective visual interpretation while supporting qualitative, semi-quantitative, and quantitative analysis. (IUL)
The iPeak® Plus is designed as a professional lateral flow reader for applications including health and veterinary diagnostics, point-of-care testing, food safety, drug testing, environmental testing, and research. Regulatory status and intended use should be confirmed for the specific product configuration and target market. (IUL)
Yes. IUL offers OEM customization of the iPeak® Plus, including product colors, logos and branding, as well as adaptations for specific lateral flow cassette designs and applications. Its design and manufacturing approach also supports customized reader development for commercial assay platforms. (IUL)
The iPeak® Plus is designed especially for larger and multi-strip lateral flow cassettes. It can accommodate configurations containing up to five strips, subject to cassette dimensions and the position of the test regions. IUL can review the cassette design and create a suitable drawer or customized reader configuration. (IUL)
